PET next rift is a luminaire belonging to the popular PET family, in the case of which you can make individual decisions about the desired length. This feature facilitates designing configurations consisting of several luminaires. In this case, the rhythmically changing length will enhance the character of an interiorBy selecting a lighting module, you define the light parameters (lighting angle and colour temperature) and the colour of the finish of this element. The colour of the lighting module is independent of the finish of the rest of the product.You decide separately what the length of the body will be. The shortest available module is 145mm (the total length of the luminaire is then 200mm = 55mm + 145mm) and grows in 100mm increments up to the total length of the luminaire, i.e., 1000mm. Finally, you choose one of the available cables: white, black or transparent.In the PET next rift system, you select a lighting module that has fixed dimensions (visible height: 55mm) and you configure the rest of the luminaire separately: the housing module.Decide separately what the length of the body will be. The shortest available module is 145mm (the total length of the luminaire is then 200mm - 55mm + 145mm) and grows in 100mm increments up to the total length of the luminaire 1000mm.Check out exapmples of PET next riftStep 1:Define the assembly.Surface or suspended.Step 3: Define the housing.Colour and length.Step 4:Define the cable For suspended version.Step 2:Define the lighting module. Light parameters and colour Create your PET next riftpower: M*: 8.5W (1140lm)CRI: CRI>90CCT: 2700K | 3000K | 4000Kbeam angle: 18° | 35° | 50°control optional: ON/OFF / DALI** white&blackFinishesLight source: LED integrated* Data for LED light source 3000K** For the housing of min. 200mmstandard structure additionalblackgreycoopergoldmixwhite
X
Lighting AQForm (Aquaform) PET next rift LED suspended
AQForm (Aquaform) PET next rift LED suspended
AQForm (Aquaform) PET next rift LED suspended
AQForm (Aquaform) PET next rift LED suspended
AQForm (Aquaform) PET next rift LED suspended
AQForm (Aquaform) PET next rift LED suspended

PET next rift LED suspended

PET next rift LED zwieszany

Light source: LED, integrated
Available colour temperature: 2700K/3000K/4000K

Dimming options: dependent on version
Integrated light source.
Gear included.

PET next rift is a system luminaire which requires the use of several components. The configurator only shows the parameters of the light emitting module.
Mix colour -06 - on white and black luminaires the colour of the decorative ring can be changed to gold, mix or ray colour from AQForm's palette.


This product contains a light source of energy efficiency class D.
Dimensional drawing of the luminaire P10015
AVAILABLE FINISHES:
STRUCTURE ADDITIONAL
  • Input voltage - 230V
  • CRI 90
  • IEC protection class - 1
  • The minimum distance from the illuminated object or surface - 0.2 m
  • Luminaire mounting point: ceiling
  • Illumination direction:
  • Optionally dimmable luminaire
  • Light source type
PRICE:
Warranty period: 5 years
